Haomei aluminum diamond plate price is calculated by unit price multiplied weight (ton). As we Calculate the piece weight of aluminum diamond plate, and we got the unit price of aluminum diamond plate form various manufacturer, we will know the specific price. Generally speaking, the thicker aluminum diamond plate are expensive than thin ones. And the 3000 series alloy aluminum diamond plates, such as grade 3003, 3105, are more cost-effective than 5000 series alloys.
Item | aluminum checkered sheet |
Grade | 1050, 1060, 1100, 3003,5052, 5083, 5086, 6061 etc. |
Temper | O, H12, H14, H16, H18, H24, H24, H26, H32, H34 |
Standard | ASTM-B209. EN573-1, GB/T3880.1-2006 |
Thickness | 0.8 - 12mm |
Width | 400-1220mm |
Length | max 6000mm for sheet or as required for coil |
Pattern | big 5 bar / small 5 bar / 3 bar / diamond / pointer |
Surface treatment | polished, mill finished, power coated, sand blast, anodized, brushed. |
Surface Protection | Oleo phobic coating,protective film,paint coating. |
Packing | Export wooden pallets. The bundle weight not exceed 2MT. Loading:by 1x20GP. |
Quality | Totally free from defects like white rust, oil patches,roll marks, edge damage, camber, dents, holes, break lines, scratches and free from coil set. |
MOQ | 1-2 Metric ton |
Free sample | Available |
Delivery time | 20-30 days after deposit |
Durable and weather & corrosive resistant
Slip resistant
Bright reflective surface and unique decorative appearance
Fire truck quality / Meets NFPA Industry Safety Regulations (Embossed only)
a. Light rail, vehicle, decorated inside and outside the car, footplate in the cars
b. Roofs, facade cladding, ceilings, decoration, building frame, windows, doors, construction
c. Stair treads, fuel tanks, piping, appliance fittings, etc
